5.2.3 Configuration
Configuring color management
• Enable: This switch will enable or disable the Application Appearance Manager.
• Manage Selected App Name: Check the box of an application to control its appearance.
• Luminance: Change the luminance of the selected managed application with this slider. Although the
slider will allow entry up to 1000 candela, the maximum luminance is the calibration luminance of the
display showing the application window. The minimum luminance is 250 candela.
Click on the palette symbol
to open controls for color management. It will be grayed out if no display
supports color profile management.
• Color Profile: Select the color profile that matches the color profile of the controlled application. Select
from sRGB, SteadyColor, and DICOM.
• White Point: Select the desired white point of a display for viewing the application. Select from D65, D75,
ClearBase, and BlueBase.
• Rendering Intent: Two rendering intents are available for the sRGB color profile: Relative and Absolute.
With Relative intent, out of gamut colors will be represented by the nearest color within the display’s color
range and other colors may shift to maintain visual differences. With Absolute intent, out of gamut colors
will be represented by the nearest color, leaving other colors intact.
• Apply: Apply the currently shown color profile settings to that application’s windows.
• Reset: Returns the color profile settings of that application’s windows to the display’s calibration settings.
5.3 Color and Grayscale Depth
5.3.1 Description
Overview
This feature allows High Dynamic Range visualization of medical imaging on gray scale and color displays.
Image 5-3
Supported display controllers
This feature is supported on all Barco MXRT display controller systems.
5.3.2 Operation
Using 30-bit desktop
30-bit desktop is enabled by default for the standard Barco MXRT driver software package. This is typically
compatible will all PACS application software.
5.3.3 Configuration
Configuring color depth
• Enable full 10-bits per color channel: Click to allow 10-bit grayscale and 30-bit color imaging.
• Limit desktop to only 8-bits per channel: Click to restrict dynamic range of grayscale to 8 bits and color
to 24 bits.
It is necessary to reboot the system to apply changes to the color depth.
