K5905271 /16 Display Controller
42
5.15 Touchpad gestures
5.15.1 Description
Overview
In addition to controlling SpotView, the Barco Touchpad can control the cursor and allows the user to control
PACS and other applications with multi-touch gestures and touchpad buttons. The user can program the
gestures and buttons to send shortcut keystrokes recognized by the PACS system.
Image 5-19
Supported display controllers
The touchpad gestures are supported by all systems with an MXRT-x400 or later display controller and the
Barco Touchpad CTH-480 or later.
5.15.2 Operation
Using the Barco Touchpad Mouse Emulation
When Mouse Emulation Mode is enabled, the user can control the cursor using the Barco Touchpad instead of
a mouse. The gestures recognized in Mouse Emulation Mode are listed in the table below. To show SpotView
with Mouse Emulation Mode enabled, hold one finger and tap a second.
Touchpad gesture
Emulated Mouse action
Move one finger Move cursor
Tap one finger Left click
Double-tap one finger Left double-click
Tap two fingers Right click
Double-tap two fingers Right double-click
Double-tap one finger, holding it the second time and
moving
Left click and drag
Double-tap two finger, holding one the second time
and moving
Right click and drag
Pinch two fingers together Control+scroll wheel down (Zoom out)
Pinch two fingers out Control+scroll wheel up (Zoom in)
Drag two fingers up Scroll wheel up
Drag two fingers down Scroll wheel down
Drag two fingers left Click scroll Wheel and drag left
Drag two fingers right Click scroll Wheel and drag right
Using the Barco Touchpad Gesture Recognition
The Barco Touchpad recognizes 10 two- and three-finger gestures: Two- and Three-finger Swipe Left, Two-
and Three-finger Swipe Right, Two- and Three-finger Swipe Up, Two- and Three-finger Swipe Down, Two-
finger Pinch In, and Two-finger Pinch Out. These are shown in the table below.
Driver and Intuitive Workflow Tools
