Display installation
30 System manual Nio 5MP
Display installation
After unpacking the display
Important:
In the factory, the height-positioning system in the
display foot is blocked with a red strap to prevent
damage during transportation.
Before installing the display, you must remove this strap.
Figure 8
To remove the strap:
1. Position the display with its rear side facing you.
2. Pull the red strap out of the fixation holes in the foot.
3. Keep the strap in case the display needs to be
shipped later.
Adjust the panel orientation
You can change the orientation of the panel at any time,
but it is more convenient to select landscape or portrait
orientation before connecting the cables.
Strap
