13. Specifications
HDMI IN (HDMI connector)
19
1
2
18
Image 13-5
Pin No. Spec
1TMDSDATA2+
2 TMDSDATA2Shield
3TMDSDATA2-
4TMDSDATA1+
5
TMDS DATA 1 Shield
6TMDSDATA1-
7
TMDS DATA 0+
8 TMDSDATA0Shield
9TMDSDATA0-
10 TMDS Clock+
11 TMDS Clock Shield
12 TMDS Clock-
13 CED
14
-
15 SCL
16 SDA
17 DCC Ground
18 +5V Power
19 Hot Plug Detection
118 R5905597 PHXX SERIES 20/05/2014
