6. Adjustments with the ADVANCED menu
100
0
0
- - -
- - -
- - -
MANUAL – SETTING
COLOR
GAIN
SATURATION
HUE
RED
WHITE R
WHITE G
WHITE B
AUTO PATTERN
ON
Image 6-20
7. Select an item you want to set by pressing the or key.
Select the color you w ant to adjust using COLOR.
When you s et AUTO PAT TERN to ON, the test pa ttern of each color is displayed.
8. Select a setting value by pressing the or key.
9. Repeat step 7 and step 8, if ne cessary.
Adjustment using a chroma meter
1. Display the M ULT I-SCREEN menu.
2. Select COLOR M AT CHING by pressing the or key.
OFF
COLOR MATCHING
Image 6-21
3. Select MEASURE by pressing the or ke y.
Set now the meas ured brightness and the chromaticity coordinates
4. Select MEASURE by pressing the or ke y.
MEASURED DATA
MEASURE
Image 6-22
5. Select MEASURED DATA by pressing the or ke y.
6. Press the ENTER key.
*
.
***
*
.
***
*
.
***
MEASURE – TARGET DATA
COLOR
GAIN
x
y
RED
AUTO PATTERN
ON
Image 6-23
7. Select an item you want to set by pressing the or key.
Select the color you want to adjust using COLOR.
When you set AUTO PATTERN to O N, the test pattern of e ach co
lor is displayed.
8. Select a setting value by pressing the or key.
9. Repeat step 7 and step 8, if ne cessary.
6.18 Resetting the settings
About reset
You can reset the SETTING , MANU AL, and MEASURE settings to the factory defaults.
How to reset
1. Display the M ULT I-SCREEN menu.
2. Select SETTING, MANUAL or MEASUR E by pressing the or key.
3. Select RESET by pressing the or key.
4. Press the ENTER key.
R5905597 PHXX SERIES 20/05/2014
67
