2. Preparing the projector
2.2 Terminology overview
Remote control
1
4
2
6
7
3
5
Image 2-1
1
ON/OFF / POWER key (ON/STANDBY)
The status is changed between ON and STANDBY.
2 Transmission windows
3 Indicators
4 ▲, ►, ▼, ◄ keys
5
OK/ENTER key
6
HOME/MENU key
7
Battery com partment
Top and side projector
2 3
6 87 9 10
4 51
9 9
Image 2-2
1
Remote control sensor (front)
2
STATUS Led
3
Indicators (inside of the top cover)
12
R5905597 PHXX SERIES 20/05/2014
