2-5 Fan Location
Fan. No
Connector
TYPE
Function
Normal
Eco
FAN0
FANS E BD(CN635)
3PIN
AFB0612HC-F00
RDMD cooling
3500 RPM
2900 RPM
FAN1
FANS E BD(CN635)
4PIN
AFB1212H-SM09
Exhaust
1500 RPM
1200 RPM
FAN2
FANS E BD(CN635)
5PIN
AFB1212H-SM09
Exhaust
1600 RPM
1300 RPM
FAN3
FANS E BD(CN635)
6PIN
AFB1212H-SM09
Exhaust
1600 RPM
1300 RPM
FAN4
FANS B BD(CN636)
3PIN
BFB1212L-SZ57
Prism cooling
1200 RPM
900 RPM
FAN5
FANS B BD(CN636)
4PIN
BFB1212L-SZ57
Engine flow inlet
1200 RPM
900 RPM
FAN6
FANS B BD(CN636)
5PIN
AFB0812HD-AF00
GDMD cooling
2100 RPM
1800 RPM
FAN7
FANS B BD(CN636)
6PIN
BFB0612HB-SE13
RDMD front cooling
2500 RPM
2500 RPM
FAN8
FANS C BD(CN637)
3PIN
AFB1212H-SM09
Power/ballast cooling
1500 RPM
1200 RPM
FAN9
FANS C BD(CN637)
4PIN
AFB1212H-SM09
Power/ballast cooling
1500 RPM
1200 RPM
FAN10
FANS C BD(CN637)
5PIN
AFB0812HD-AF00
BDMD cooling
2300 RPM
2000 RPM
FAN11
FANS C BD(CN637)
6PIN
BFB0612HB-SE13
BDMD front cooling
2500 RPM
2500 RPM
FAN20
CN646(PWM)OnBoard
4PIN
BFB0712HD-SP01
Lamp burner
4000 RPM
3300 RPM
FAN21
CN647(PWM)OnBoard
5PIN
BFB0712HD-SP01
Lamp burner
2000 RPM
2000 RPM
FAN22
CN648(PWM)OnBoard
6PIN
BFB0712HD-SP01
Lamp burner
4000 RPM
3300 RPM
FAN23
CN649(PWM)OnBoard
7PIN
BFB0712HD-SP01
Lamp burner
2000 RPM
2000 RPM
FAN-R1
BFB0712LD-SE00
FPGA cooling
12V
12V
