APPENDIX. TIMING TABLE
A . SIGNAL REQUIREMENT
ALL SIGNAL MUST BE AVAILABLE WITH CHROMA
SIGNAL A FULL WHITE PATTERN, CHROMA PATTERN #41
SIGNAL B FULL BLACK PATTERN,CHROMA PATTERN #11
SIGNAL C COLOR BARS: EIGHT 100 PIXEL WIDE BARS.
SIGNAL D CROSSHATCH, CHROMA PATTERN #1.
B . TIMING OF INPUT SIGNALS
NOMINAL INPUT LEVE SPECIFICATION.
SIGNAL A. DATA VGA INPUT LEVEL
ANALOG VIDEO RGB : 0.7Vpp 75 ohm. POSITIVE.
SEPARATE SYNC : LOW =0V MIN.~0.65V MAX.
HIGH= 2.8V MIN.~5.5V MAX.
POSITIVE/NEGATIVE. 1K ohm.
