Barco RLM W12

57 of 123
4-12 Front Cover & Front IR Board
Loosen 1 screw on right bottom side of
front cover.
Loosen 4 screws on the right side of right
cover.
Take off the front cover.
Front Cover
Unplug 1 connector and loosen 1 screw
on front IR board.
Take off the front IR Board.
