Barco RLM W12

48 of 123
4-8 Back Cover & Keypad & Rear IR Board
Loosen 4 screws on the right and bottom
side of cover.
Loosen 8 screws on the left side of cover and
two Fan modules.
Take off the back cover.
Loosen 4 screws and unplug 1 connector on
the rear cover.
