Barco RLM W12 Operation Commands
Command
Item
Operation
Commands
Values
Notes
3-2
pip.sel
= ?
1 = HDMI 1
2 = HDMI 2
3 = RGB D-15
4 = YUV 1
5 = RGBHV/YUV2
6 = Composite Video
7 = S-Video
8 = RGB-S
9 = SDI/HDSDI/3G
Note1;
Note9;
Please refer to appendix 1
for the valid main/pip
source selection
3-3
pip.pos
= ?
0 = Top left
1 = Top right
2 = Bottom left
3 = Bottom right
4 = Split L-R
Note1;
Note10
3-4
pip
= ?
0 = Off
1 = On
Note1
4-1
lamp.mode
= ?
0 = Economy
1 = Standard
2 = Dimming
Note2
4-2
lamps
= ?
0 = Single
1 = Dual
Note1;
Note11
4-3
altitude
= ?
0 = Off
1 = On
Note1
4-4
lamp.pwr
= ?
0-26 ( 79.6 % ~100.0 % )
Note2
4-5
lamp1.stat
?
0 = Off
1 = On
Note1
4-6
lamp2.stat
?
0 = Off
1 = On
Note1
5-1
rear.proj
= ?
0 = front
1 = rear
Note1
5-2
ceil.mode
= ?
0 = floor
1 = ceiling
Note1
5-3
zoomio
+ -
+ = Zoom out
- = Zoom in
Motor command;
Note1
