Barco RLM W12 Service Manual

29 of 123
Barco RLM W12 Operation Commands
Command
Item
Operation
Commands
Values
Notes
0.9
darkTm.sel
= ?
0 = 650 us
1 = 1300 us
2 = 1950 us
Note 19
0.10
3dsync.inv
= ?
0 = off
1 = on
Note 19
0.11
3dsync.dly
= ? + -
-32768 ~ 32767
Note 19
In microseconc
REMARK: An input command will get back with “NA” when the input command is “Not Applicable”
in some specific conditions.
Note1: Not applicable in standby mode.
Note2: Not applicable in standby mode or without signal locked.
Note3: Not applicable when picture mute is on.
Note4: Only valid when source is one of Composite, S-Video and RGB-S.
Note5: Native aspect ratio is not applicable when zoom is set to “Zoom”; Letterbox aspect ratio is not
applicable when the input format is one of formats as listed in appendix 2.
Note6: Selection “Zoom” is not applicable when aspect ratio is set to Native.
Note7: Only applicable when source is one of RGB D-15, YUV1 and RGBHV/YUV2.
Note8: Not applicable when color space is set to custom.
Note9: pip.sel can NOT be set to 0.
Note10: Not applicable when pip is off.
Note11: Not applicable when lamp is cooling.
Note12: Not applicable when eco.net.pow is on.
Note13: Only MCU version number will be read back in standby mode.
Note14: Not applicable when the internal pattern is displayed.
Note15: The summation of the absolute value of h.keystone and v.keystone should not be greater
than 350.
Note16: Per Geo Semi’s specification, the minimum blend size is 200, values in the range 1~199 are
not allowed
Note17: Per Geo Semi’s specification, black level (position) adjustment will only work with an active
white level setting on the corresponding side.
Note18: When scen.red, scen.green, scen.blue values are not equal, the command will get back “NA”
in reading.
Note19: Only available when “STEREO DVI” source is active

Barco RLM W12 Specifications

General

Matrix size	0.96 \
Heat dissipation	3412 BTU/h
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	1600:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Focal length range	- mm
Lamp power	400 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Full HD	Yes
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
CardBus PCMCIA slot type	No
Ethernet LAN data rates	10, 100 Mbit/s
Optical disc player type	Not included
Noise level	43 dB
Certification	FCC part 15 Class A, CE EN55022 Class A, CE, TUV, WEEE
Dot clock scanning frequency	165 MHz
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1000 W
Power consumption (standby)	2 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Remote control type	IR

Weight and Dimensions

Depth	631 mm
Width	500 mm
Height	270 mm
Weight	32000 g
Package depth	830 mm
Package width	669 mm
Package height	448 mm
