40 of 123
Loosen 6 screws on the I/O terminal of
the slave board on the left cover.
Unplug 10 connectors on the top right of
Slave board.
Unplug 5 connectors on the top left of
Slave board.
Unplug 5 connectors on the top left of Slave
board.
Unplug 4 connectors on the bottom left of
Slave board.
Loosen 3 screws on the Slave board.
