6 Installing Software
The Site~Rite* 5 Ultrasound System allows software installation through the USB connectors located on the
rear of the scanner.
To install software:
1. Press the Freeze button ( ) to pause the system.
2. Insert a USB drive into one of the USB connectors located on the rear of the Site~Rite 5 scanner.
3. Wait until the storage device icon is illuminated before proceeding.
4. Simultaneously press and hold the Gain buttons ( ) until the configuration screen appears.
5. When the configuration screen appears, simultaneously press and hold the Depth button (
cm ) and
Depth Marker button (
/:\
) until the software installation process begins.
Note:
The Site~Rite 5 System will automatically upload the software from the attached USB drive.
Note:
The screen will appear blank and/or inactive during the software installation process.
6. When a blinking cursor appears, power off the Site~Rite 5 scanner.
7. Disconnect the USB drive.
8. Power on the Site~Rite 5 scanner.
9. Verify that the correct software version appears on the upper left hand corner of the screen.
10. Resume normal operation.
