13
Figure 2.4.2. Internal view of the MR3000DMS with DC power.
2.4.1. Internal display
The LCD of the MR3000DMS shows the most important settings and parameters. In particular,
there are two types of screen, that are changing constantly. The first one, as can be seen in Figure
2.4.3a, indicates general parameters related to the MR3000DMS:
LINE 1. Typology of the instrument, together with the battery voltage
11
9
7
6
4
3
1
2
5
