TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 15 -
CHASSIS BOM
Item # Description Item # Description Item # Description
1 Chassis Weldment 22 Washer 43 Hex Bolt
2 Seat Frame 23 Lockwasher 44 Hex Bolt
3 TS100 End Ring 24 Hex Bolt 45 Hex Nut
4 Heat Shield Weldment 25 Hex Bolt 46 Hex Bolt
5 Front Floor Plate 26 Washer 47 Lock Nut
6 Rear Floor Panel 27 Lock Nut 48 Lock Nut
7 Front Seat Frame Panel 28 Washer 49 Prop Rod
8 Rear Seat Frame Panel 29 Lockwasher 50 Hour Meter
9 Instrument Panel 30 Throttle Cable 51 Control Lamp
10 TS100 Hinge Plate 31 Ball Joint 52 Starter Key Switch
11 Seat 32 Dead Man Pedal Bracket 53 Socket Screw
12 Fuel Tank 33 Hex Bolt 54 Lock Nut
13 Joystick Box 34 Gas Pedal Bracket 55 Flatwasher
14 Joystick Box 35 Lock Nut 56 Anti-Vibration Mount
15 Pitch Control 36 Gas Pedal 57 Hex Bolt
16 Sheet Metal Screw 37 Deadman Pedal 58 Battery Box
17 Lamp 38 Lockwasher 59 Rubber Grommet
18 Fuel Tank Neck 39 Hex Bolt 60 Hex Bolt
19 Fuel Cap With Gauge 40 Throttle Clip 61 Hex Nut
20 Lockwasher 41 Lockwasher 62 Oil Tank
21 Machine Screw 42 Machine Screw
