Bartell TS100 - Drive Train Parts List

TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 21 -
CUSTOMER PARTS LIST
Assembly #
Drive Train Assembly
Item # Part # Description Qty Eff. Date
1 14327 Spider Plate Ass’y 1 7/29/04
2 14328 Spider Plate Ass’y 1 7/29/04
3 14016 Gearbox Ass'y – LH 1 7/29/04
4 14015 Gearbox Ass'y – RH 1 7/29/04
5 14100 Mounting Plate Set 2 7/29/04
6 13903 Mounting Bracket – RH 2 7/29/04
7 13900 Pivot Bracket – RH 1 7/29/04
8 13904 Mounting Bracket – LH 1 7/29/04
9 14071 Pitch Control Bracket – LH 1 7/29/04
10 14072 Pitch Control Bracket – RH 1 7/29/04
11 14340 Control Arm 2 7/29/04
12 14116 Pressure Plate Ass’y 2 7/29/04
13 14337 Trowel 6” x 18” 10 7/29/04
14 14027 U-Joint Driveshaft - #1310 2 7/29/04
15 10902 Lockwasher 3/8" 24 7/29/04
16 10507 HHCS 3/8-16UNC x 1"LG 16 7/29/04
17 12745 Set Screw 3/8-16UNC x .750 6 7/29/04
18 10269 HHCS 7/16-20UNF x 1-1/2"LG 8 7/29/04
19 13488 Hex Locknut 7/16-20UNF Nylon 8 7/29/04
20 13570 Flange Bearing 20mm ID 4 7/29/04
21 10608 Key 1/4" Sq x 1-5/32"LG 3 7/29/04
22 14123 Key 3/8” Sq x 1-5/8"LG 2 7/29/04
23 14099 Spider Plate Retainer 2 7/29/04
24 10802 SHCS 1/2-13UNC x 1-1/2"LG 2 7/29/04
25 13246 Flange Bearing UCFL 206-104D1 4 7/29/04
26 10009 Lockwasher 1/2" 8 7/29/04
27 13498 HHCS 1/2-13UNC x 1-3/4"LG 8 7/29/04
28 12930 Fender Washer, 1/2 Dia. 8 7/29/04
29 12519 Hex Nut 1/2-13UNC 8 7/29/04
30 14029 Jackshaft TS100 1 7/29/04
31 14032 Driveshaft TS100 1 7/29/04
32 14150 Key 1/4”Sq x 1-5/8”LG 2 7/29/04
33 13859 Sheave,B Sect,5.6 Dia,3 Groove 1 7/29/04
34 14627 Bushing Qd, SD x 1-1/4" Bore 1 7/29/04
35 14024 Bushing Qd, SK x 1-1/4" Bore 1 7/29/04
36 14022 Sheave B Sect, 9.0"Dia. 3 Groove 1 7/29/04
37 14151 Key 1/4”Sq x 3-1/2”LG 1 7/29/04
38 13205 Bushing Taperlock 2015 x 1-1/4" 1 7/29/04
39 14611 Sheave, 3D80, SK Bushing 1 7/29/04
40 14613 Belt – BX40 3 7/29/04
41 14610 Belt – BX44 3 7/29/04
42 10913 Retaining Ring 7/16"Dia Shaft 4 7/29/04
43 14039 Yoke Arm 2 7/29/04
44 14081 Yoke Arm Pin 2 7/29/04
45 12593 Flanged Bushing 2 7/29/04
46 10901 Hex Nut 3/8-16UNC 8
