Bartell TS100 - Gearbox Parts List

TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 25 -
CUSTOMER PARTS LIST
Assembly #
14015(RH), 14016(LH)
Gearbox
Item #
14015
RH
14016
LH
Description Qty Eff. Date
1 14002 14004 Gearbox Bottom Half 1 7/29/04
2 14001 14003 Gearbox Top Half 1 7/29/04
3 14006 14005 Worm Gear, 4-Pitch 1 7/29/04
4 14017 14017 Mainshaft 1 7/29/04
5 13580 13580 Key - Mainshaft Heavy GB. 1 7/29/04
6 13563 13563 Mainshaft Bearing 2 7/29/04
7 13910 13910 Mainshaft Bearing - Bottom 2 7/29/04
8 14008 14007 Worm Shaft, 4-Pitch 1 7/29/04
9 14012 14012 Retaining Ring – Input 1 7/29/04
10 14010 14010 Gearbox Input Seal 1 7/29/04
11 14013 14013 Coutershaft Cap 1 7/29/04
12 14009 14009 Retaining Ring - 3000-X315 1 7/29/04
13 13515 13515 View Gauge 1 7/29/04
14 10909 10909 Relief Valve 1 7/29/04
15 13532 13532 Magnetic Drain Plug 1 7/29/04
16 10902 10902 Lockwasher 3/8" 11 7/29/04
17 13914 13914 HHCS 3/8-16 x 4"LG 11 7/29/04
18 14011 14011 Mainshaft Seal 1 7/29/04
19 10589 10589 Washer 3/16" 2 7/29/04
20 10513 10513 RHMS, #10-24UNC x 1/4"LG, Sq. Head 2 7/29/04
21 14014 14014 O-Ring Seal 1 7/29/04
