Bartell TS100 - Chassis Parts List

TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 16 -
CUSTOMER PARTS LIST
Assembly #
Chassis Assembly
Item # Part # Description Qty Eff. Date
1 14050 Chassis Weldment 1 6/22/05
2 14666 Seat Frame 1 6/22/05
3 14135 TS100 End Ring 2 6/22/05
4 14690 Heat Shield Weldment 1 6/22/05
5 14051 Front Floor Plate 1 6/22/05
6 14052 Rear Floor Panel 1 6/22/05
7
14084
Front Seat Frame Panel 1 6/22/05
8 Rear Seat Frame Panel 1 6/22/05
9 14154 Instrument Panel 1 6/22/05
10 14662 TS100 Hinge Plate 1 6/22/05
11 14581 Seat - With Armrest 1 6/22/05
12 14323 Fuel Tank, 6.5 Gal 1 6/22/05
13 14526 Joystick Box Ass'y - RH 1 6/22/05
14 14525 Joystick Box Ass'y - LH 1 6/22/05
15 14122 Pitch Control Ass'y 2 6/22/05
16 14596 HWHS 1/4-20 x 1/2"LG Thread Cutting 30 6/22/05
17 12528 Lamp 55 Watts 4 6/22/05
18 14322 Fuel Tank Neck 1 6/22/05
19 14321 Fuel Cap With Gauge 1 6/22/05
20 14600 Lockwasher,Ext. Tooth,#10, Zinc Plated 11 6/22/05
21 14590 RHMC #10-32 x 3/8"LG (Phillips) 11 6/22/05
22 10905 Washer 3/8" (M10) 16 6/22/05
23 10902 Lockwasher 3/8" 20 6/22/05
24 30181 HHCS 3/8-16 x 3/4"LG 8 6/22/05
25 30031 HHCS 1/4-20UNC x 1/2"LG 2 6/22/05
26 11586 Washer 5/16" 12 6/22/05
27 11554 Nylock Nut #10-32 1 6/22/05
28 11043 Washer 1/4" 2 6/22/05
29 10521 Lockwasher, 1/4"Dia 8 6/22/05
30 14043 Throttle Cable 50"LG 1 6/22/05
31 11124 Ball Joint 1 6/22/05
32 14605 Dead Man Pedal Bracket 1 6/22/05
33 10963 HHCS 1/4-20 x 3/4"LG 16 6/22/05
34 14606 Gas Pedal Bracket 1 6/22/05
35 30141 Nylock Nut 1/4-20UNC 10 6/22/05
36 22546 Gas Pedal 1 6/22/05
37 22547 Deadman Pedal 1 6/22/05
38 10402 Lockwasher 5/16" 16 6/22/05
39 30142 HHCS 5/16-18UNC x 3/4"LG 2 6/22/05
40 13863 Throttle Clip 1 6/22/05
41 10703 Lockwasher #10 Internal Tooth 2 6/22/05
42 10706 HHMS #10-24 x 1/2"LG 2 6/22/05
43 13312 HHCS 3/8-16UNC x 1-1/4"LG 8 6/22/05
44 30008 HHCS 5/16 - 18 x 1 3/4 2 6/22/05
45 10915 Hex Nut 5/16-18UNC 14 6/22/05

Continued on next page…
