Bartell TS100 - Pitch Control Assembly Parts List

TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 27 -
CUSTOMER PARTS LIST
Item # Part # Description Qty Eff. Date
1 22538 Pitch Control Tube 1 12/8/04
2 10303 Screw Shaft 1 12/8/04
3 10308 Slide Bushing 1 12/8/04
4 10307 Retainer 1 12/8/04
5 10306 Washer 3/4”Dia 1 12/8/04
6 10305 Screw Shaft 1 12/8/04
7 10304 Bearing 607V Nice 1 12/8/04
8 12894 Coupling Handle Ass’m 1 12/8/04
9 13015 Spring Pin 3/16”Dia x 1-1/4” 1 12/8/04
10 10510 SHCS 1/4-20 x 3/8”LG 1 12/8/04
11 10309 Spring Pin 3/16”Dia x 1-1/2”LG 1 12/8/04
12 22539 Control Cable 1 12/8/04
13 10511 RHMS 1/4-20 x 3/8”LG Slotted 1 12/8/04
14 10521 Lockwasher, 1/4”Dia 1 12/8/04
Assembly #
22551
Pitch Control Assembly
