Bartell TS100 - TRANSPORTER HANDLE ASSEMBLY

TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 38 -
TRANSPORTER HANDLE ASSEMBLY
Figure 13 – TS100 Transporter Assembly
Item # Description Item # Description
1 Wheel 7 Pin
2 Bushing 8 Hex Bolt
3 Spacer 9 Upper Dolly Ass’y
