TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 19 -
CUSTOMER PARTS LIST
Assembly #
Powerplant Assembly
Item # Part # Description Qty Eff. Date
1 21367 Kubota V1505 38 HP, 3000 RPM 1 6/23/05
2 14145 Pulley Mount Bracket – LH 1 6/23/05
3 14144 Pulley Mount Bracket – RH 1 6/23/05
4 14119 Kubota Mnt'ing Brkt. - 1/2" 1 6/23/05
5 14120 Kubota Mnt'ing Brkt. - 5/16" 1 6/23/05
6 14117 Throttle Bracket 1 6/23/05
7 14222 Stub Shaft, 38 Hp Kubota 1 6/23/05
8 12793 Clutch/Drive Pulley (BLM) 1 6/23/05
9 11124 Ball Joint 1 6/23/05
10 10402 Locknut 5/16" 2 6/23/05
11 30142 HHCS 5/16-18 UNC x 3/4"LG 2 6/23/05
12 21367 Kabuta Gas Filter (comes with engine) 1 6/23/05
13 11314 Thick Washer 0.433”ID 1 6/23/05
14 10009 Lockwasher 1/2" 5 6/23/05
15 10008 HHCS 1/2-13 x 1-1/4"LG 1 6/23/05
16 12089 Lockwasher 10mm 6 6/23/05
17 12088 HHCS M10 x 1.25 - 30mm (8.8) 22 6/23/05
18 11003 Key 1/4" Sq x 2"LG 1 6/23/05
19 50026 Washer 1/2” 4 6/23/05
20 10955 HHCS 12mm-1.25 x 40mm, (8.8) 4 6/23/05
21 11621 Lockwasher 10mm 16 6/23/05
22 13963 Spacer 1.125"ID x 1-1/8"LG 1 6/23/05
To Next Page
