TS100 RIDE-ON TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
Created: 06/05
Revised: 06/14
- 36 -
TRANSPORTER ASSEMBLY - CONTINUED
Figure 12 – TS100 Dolly Ass’y
Note: Left hand Dolly Shown.
Item # Description Item # Description
1 Wheel 7 Pin
2 Bushing 8 Hex Bolt
3 Spacer 9 Upper Dolly Ass’y
4 Lockwasher 10 Wheel Yoke
5 Bushing 11 Lower Dolly Ass’y
6 Cotter Pin
