CUSTOMER PARTS LIST
Assembly #
Steering Assembly
Item # Part # Description Qty Eff. Date
1 10306 Washer 3/4"Dia 2 7/29/04
2 12517 Nylock Nut, 1/2-20UNF 2 7/29/04
3 13578 Nylock Nut 5/8-11UNC 4 7/29/04
4 12412 Rod End Pivot Ass'y - Female/Male 2 7/29/04
5 12592 Hex Jam Nut 1/2-20UNF 1 7/29/04
6 12659 Threaded Rod 1/2-20 x 3-1/4"LG 1 7/29/04
7 14551 Rod End, Female Con, 5/8-18UNF 2 7/29/04
8 14552 Rod End VCW-10S 5/8-18UNF 1 7/29/04
9 13481 SHSB 3/4"Shldr x 5/8-11 x 1-1/4"LG 2 7/29/04
10 14142 Lever Pin LH/RH 1 7/29/04
11 14065 Bushing 2 7/29/04
12 14141 Lever, LH/RH 1 7/29/04
13 14348 Fitting,Male Adapter,Brass,#6JIC-#6SAE 12 7/29/04
14 14349 Fitting,Male Adaptor,Brass,#8 JIC - #8 SAE 1 7/29/04
15 14508 Hydraulic Manifold Block 1 7/29/04
16 14507 Hydraulic Joystick - 4 Way 1 7/29/04
17 14506 Hydraulic Joystick - 2 Axis 1 7/29/04
18 14513 Hydraulic Cyclinder, .50BC2MLTS13A2.50 1 7/29/04
19 14324 Oil Tank, TS100 1 7/29/04
20 14505 Hydraulic Cylinder 2 7/29/04
21 14342 Pivot Arm Weldment 2 7/29/04
22 10315 Pin 3/16"Dia x 1-1-4"LG 2 7/29/04
23 14343 Rod End, 1"Bore, 1-1/4-12 2 7/29/04
24 14373 Jam Nut 1-1/4-12, Plated 2 7/29/04
25 14503 Suction Strainer 1 7/29/04
26 14356 Hydraulic Hose Ass'y 4 7/29/04
27 14318 Oil Level Sight Gauge 4 7/29/04
28 14263 Spacer 2 7/29/04
29 14502 Tank Top Filter 1 7/29/04
30 14504 Hydraulic Tank Gauge 1 7/29/04
31 10963 HHCS 1/4-20 x 3/4"LG 2 7/29/04
32 10521 Lockwasher 1/4" 2 7/29/04
33 14514 Hydraulic Tank Cover 1 7/29/04
34 14600 Lockwasher, Int. Tooth #10 10 7/29/04
35 14599 Truss Screw #10-32 x 1/2"LG 10 7/29/04
To Next Page
