Basler DECS-150 User Manual

9492600990 25-17
DECS-150 Modbus
®
Communication
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Per Unit Meter
Negative Sequence Current
1028
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Vab
1030
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Vbc
1032
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Vca
1034
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus V Average
1036
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Voltage Difference
1038
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Power in Voltage
1040
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Control Out Var PF
1042
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Control Out OEL
1044
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Control Out UEL
1046
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Control Out SCL
1048
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Control Out AVR
1050
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Control Out FCR
1052
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Null Balance Percent
1054
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Generator Frequency
1056
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Frequency
1058
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Ifd
1060
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Vfd
1062
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Slip Frequency
1064
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Icc
1066
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
AVR Setpoint
1068
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
FCR Setpoint
1070
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
FVR Setpoint
1072
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Var Setpoint
1074
Float
4
R
Per Unit
-10 – 10
Field Current Meter
I
X
1076
Float
4
R
Amp
0–2000000000
DECS PSS Meter
Terminal Frequency Deviation
1078
Float
4
R
Percent
n/a
DECS PSS Meter
Compensated Frequency
Deviation
1080
Float
4
R
Percent
n/a
DECS PSS Meter
PSS Output
1082
Float
4
R
n/a
n/a
DECS Regulator Meter
Tracking Error
1084
Float
4
R
Percent
n/a
DECS Regulator Meter
Control Output PU
1086
Float
4
R
Per Unit
-10 – 10
DECS Regulator Meter
Exciter Diode Monitor Ripple
1088
Float
4
R
Amp
0–2000000000
DECS Regulator Meter
Power Input
1090
Float
4
R
Volt
0–2000000000
DECS Regulator Meter
Control Output
1092
Float
4
R
Percent
n/a
DECS Regulator Meter
V1 Phase Angle
1094
Float
4
R
Degree
0–360
Reserved
1096-
1106
Generator Voltage Meter
Primary 1
V
AB
1108
Float
4
R
Volt
0–2000000000
Generator Voltage Meter
Primary 1
V
BC
1110
Float
4
R
Volt
0–2000000000
Generator Voltage Meter
Primary 1
V
CA
1112
Float
4
R
Volt
0–2000000000
Generator Voltage Meter
Primary 1
V1 L
1114
Float
4
R
Volt
0–2000000000
Generator Voltage Meter
Primary 1
V2 L
1116
Float
4
R
Volt
0–2000000000
Generator Voltage Meter
Primary 1
V
AVG
LL
1118
Float
4
R
Volt
0–2000000000
Generator Voltage Meter
Angle 1
V
AB
1120
Float
4
R
Degree
0–360
Generator Voltage Meter
Angle 1
V
BC
1122
Float
4
R
Degree
0–360
Generator Voltage Meter
Angle 1
V
CA
1124
Float
4
R
Degree
0–360
