Basler DECS-150 User Manual

25-18 9492600990
Modbus
®
Communication DECS-150
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Reserved
1126-36
Bus Voltage Meter Primary 1
V
AB
1138
Float
4
R
Volt
0–2000000000
Bus Voltage Meter Primary 1
V
BC
1140
Float
4
R
Volt
0–2000000000
Bus Voltage Meter Primary 1
V
CA
1142
Float
4
R
Volt
0–2000000000
Bus Voltage Meter Primary 1
V1 L
1144
Float
4
R
Volt
0–2000000000
Bus Voltage Meter Primary 1
V2 L
1146
Float
4
R
Volt
0–2000000000
Bus Voltage Meter Primary 1
V
AVG
LL
1148
Float
4
R
Volt
0–2000000000
Bus Voltage Meter Angle 1
V
AB
1150
Float
4
R
Degree
0–360
Bus Voltage Meter Angle 1
V
BC
1152
Float
4
R
Degree
0–360
Bus Voltage Meter Angle 1
V
CA
1154
Float
4
R
Degree
0–360
Reserved
I
A
1156-69
Generator Current Meter
Primary 1
I
A
1168
Float
4
R
Amp
0–2000000000
Generator Current Meter
Primary 1
I
B
1170
Float
4
R
Amp
0–2000000000
Generator Current Meter
Primary 1
I
C
1172
Float
4
R
Amp
0–2000000000
Generator Current Meter
Primary 1
I1
1174
Float
4
R
Amp
0–2000000000
Generator Current Meter
Primary 1
I2
1176
Float
4
R
Amp
0–2000000000
Generator Current Meter
Primary 1
I
AVG
1178
Float
4
R
Amp
0–2000000000
Generator Current Meter
Angle 1
I
A
1180
Float
4
R
Degree
0–360
Generator Current Meter
Angle 1
I
B
1182
Float
4
R
Degree
0–360
Generator Current Meter
Angle 1
I
C
1184
Float
4
R
Degree
0–360
Icc Current Meter
Magnitude 1
I
X
1186
Float
4
R
Amp
0–2000000000
Icc Current Meter Primary 1
I
X
1188
Float
4
R
Amp
0–2000000000
Power Meter
Total watts primary
1190
Float
4
R
Watt
n/a
Power Meter
Total vars primary
1192
Float
4
R
var
n/a
Power Meter
Total S primary
1194
Float
4
R
VA
n/a
Power Meter
Total PF primary
1196
Float
4
R
PF
-1 – 1
Sync Meter 1
Slip Angle
1198
Float
4
R
Degree
-359.9 – 359.9
Sync Meter 1
Slip Frequency
1200
Float
4
R
Hertz
n/a
Sync Meter 1
Voltage Difference
1202
Float
4
R
Volt
n/a
Generator Frequency
Meter 1
Frequency
1204
Float
4
R
Hertz
10–180
Bus Frequency Meter 1
Frequency
1206
Float
4
R
Hertz
10–180
Auxiliary Input Voltage 1
Value
1208
Float
4
R
Volt
-9999999 –
9999999
Auxiliary Input Current 1
Value
1210
Float
4
R
Amp
-9999999 –
9999999
Energy Meter
Positive watthour total
1212
Float
4
RW
Watthour
0.00E+00 –
1.00E+09
Energy Meter
Positive varhour total
1214
Float
4
RW
Varhour
0.00E+00 –
1.00E+09
Energy Meter
Negative watthour total
1216
Float
4
RW
Watthour
-1.00E+09 –
0.00E+00
Energy Meter
Negative varhour total
1218
Float
4
RW
Varhour
-1.00E+09 –
0.00E+00
Energy Meter
VA hour total
1220
Float
4
RW
Varhour
0.00E+00 –
1.00E+09
DECS Regulator Meter
NLS Error Percent
1222
Float
4
R
Percent
n/a
DECS Regulator Meter
Current Magnitude Pickup
1224
Float
4
R
Per Unit
-10 – 10
