Basler DECS-150 User Manual

9492600990 25-19
DECS-150 Modbus
®
Communication
Group
Name
Register
Type
Bytes
R/W
Unit
Range
DECS Regulator Meter
NLS Current Magnitude Average
Pickup
1226
Float
4
R
Per Unit
-10 – 10
DECS Regulator Meter
NLS Number of Generators
Online
1228
Int32
4
R
n/a
n/a
Field Voltage Meter
Vx
1230
Float
4
R
Volt
-1000 – 1000
Grid Code
Q Reference
1232
Float
4
R
Per Unit
-10 – 10
Grid Code
P Reference
1234
Float
4
R
Per Unit
-10 – 10
Grid Code
State
1236
Uint32
4
R
n/a
Inactive=0
Active=1
Grid Code
Grid Connect State
1238
Uint32
4
R
n/a
Disabled=0
GCC Continuous
Operation=1
GCC Frequency
Low Timing=2
GCC Frequency
High Timing=3
GCC Voltage Low
Timing=4
GCC Voltage High
Timing=5
GCC Out of
Range Timing=6
GCC
Disconnected=7
GCC Timing for
Reconnect=8
Grid Code
Grid Disconnect Flag
1240
Int32
4
R
n/a
n/a
Grid Code
LVRT Mode
1242
Uint32
4
R
n/a
Disabled=0
Q(PF)=1
Q(Voltage
Limit)=2
Q(U)=3
Q(P)=4
Q(Third Party)=5
Freeze Output=6
Grid Code
LFSM Mode
1244
Uint32
4
R
n/a
Initialize=0
Nominal=1
Underfrequency=2
Overfrequency=3
Recovery=4
Grid Code
Remote LVRT Status
1246
Uint32
4
R
n/a
Disabled=0
Active=1
Failed=2
Grid Code
Remote LFSM Status
1248
Uint32
4
R
n/a
Disabled=0
Active=1
Failed=2
Grid Code
PF Mode Reference
1250
Float
4
R
n/a
n/a
Grid Code
Q U Mode Reference
1252
Float
4
R
Per Unit
-10 – 10
Grid Code
Q Voltage Limit Mode Reference
1254
Float
4
R
Per Unit
-10 – 10
Grid Code
Q Third Party Mode Reference
1256
Float
4
R
Per Unit
-10 – 10
Grid Code
APC Reference
1258
Float
4
R
Per Unit
-10 – 10
Grid Code
LVRT Modbus Comm Fail Timer
1260
Float
4
R
Second
0–600
Reserved
1262
Grid Code
APC Modbus Comm Fail Timer
1264
Float
4
R
Second
0–600
Reserved
1266
Grid Code
APC Integrator State
1268
Float
4
R
Per Unit
-10 – 10
Grid Code
APC Error
1270
Float
4
R
Per Unit
-10 – 10
Grid Code
APC P Desired
1272
Float
4
R
Per Unit
-10 – 10
Grid Code
APC Bias Voltage
1274
Float
4
R
n/a
n/a
Grid Code
LVRT Q Desired
1276
Float
4
R
Per Unit
-10 – 10
Grid Code
LVRT Bias Voltage
1278
Float
4
R
n/a
n/a
Grid Code
Test Signal
1280
Float
4
R
n/a
n/a
Reserved
1282
Reserved
1284
