Basler DECS-150 User Manual

25-20 9492600990
Modbus
®
Communication DECS-150
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Reserved
1286
Reserved
1288
Reserved
1290
Grid Code
Active Power Adjust Modbus
1292
Float
4
R
Per Unit
-10 – 10
Grid Code
PF Reference Adjust Modbus
1294
Float
4
R
n/a
n/a
Grid Code
Q Voltage Limit Adjust Modbus
1296
Float
4
R
Per Unit
-10 – 10
Grid Code
Q U Voltage Bus for Zero Q
Adjust Modbus
1298
Float
4
R
Per Unit
-10 – 10
Grid Code
Q Third Party Adjust Modbus
1300
Float
4
R
Per Unit
-10 – 10
Grid Code
APC Mode
1302
Uint32
4
R
n/a
Inactive=0
Active=1
LFSM Override=2
Grid Code
Grid Connect Voltage Timer
1304
Float
4
R
Second
0–2000
Grid Code
Grid Connect Frequency Timer
1306
Float
4
R
Second
0–2000
Grid Code
Grid Connect Disconnect Timer
1308
Float
4
R
Second
0–2000
Grid Code
Grid Connect Reconnect Timer
1310
Float
4
R
Second
0–2000
Limiters
Table 25-8. Limiter Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
OEL Primary Current Hi
1700
Float
4
R W
Amp
0–11
OEL Primary Current Mid
1702
Float
4
R W
Amp
0–9
OEL Primary Current Lo
1704
Float
4
R W
Amp
0–7
OEL Primary Time Hi
1706
Float
4
R W
Second
0–10
OEL Primary Time Mid
1708
Float
4
R W
Second
0–120
OEL Primary Current Hi Off
1710
Float
4
R W
Amp
0–11
OEL Primary Current Lo Off
1712
Float
4
R W
Amp
0–7
OEL Primary Current Time Off
1714
Float
4
R W
Second
0–10
OEL Primary Takeover Current Max Off
1716
Float
4
R W
Amp
0–11
OEL Primary Takeover Current Min Off
1718
Float
4
R W
Amp
0–7
OEL Primary Takeover Time Dial Off
1720
Float
4
R W
n/a
0.1–20
OEL Primary Takeover Current Max On
1722
Float
4
R W
Amp
0–11
OEL Primary Takeover Current Min On
1724
Float
4
R W
Amp
0–7
OEL Primary Takeover Time Dial On
1726
Float
4
R W
n/a
0.1–20
OEL Primary Dvdt Enable
1728
Uint32
4
R W
n/a
Disabled=0 Enabled=1
OEL Primary Dvdt Ref
1730
Float
4
R W
n/a
-10 – 0
OEL Secondary Current Hi
1732
Float
4
R W
Amp
0–11
OEL Secondary Current Mid
1734
Float
4
R W
Amp
0–9
OEL Secondary Current Lo
1736
Float
4
R W
Amp
0–7
OEL Secondary Time Hi
1738
Float
4
R W
Second
0–10
OEL Secondary Time Mid
1740
Float
4
R W
Second
0–120
OEL Secondary Current Hi Off
1742
Float
4
R W
Amp
0–11
OEL Secondary Current Lo Off
1744
Float
4
R W
Amp
0–7
OEL Secondary Current Time Off
1746
Float
4
R W
Second
0–10
OEL Secondary Takeover Current Max Off
1748
Float
4
R W
Amp
0–11
OEL Secondary Takeover Current Min Off
1750
Float
4
R W
Amp
0–7
OEL Secondary Takeover Time Dial Off
1752
Float
4
R W
n/a
0.1–20
OEL Secondary Takeover Current Max On
1754
Float
4
R W
Amp
0–11
OEL Secondary Takeover Current Min On
1756
Float
4
R W
Amp
0–7
OEL Secondary Takeover Time Dial On
1758
Float
4
R W
n/a
0.1–20
UEL Primary Curve X1
1760
Float
4
R W
kilowatt
0–62
UEL Primary Curve X2
1762
Float
4
R W
kilowatt
0–62
