Modbus
®
Communication DECS-150
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Gen Current
Configuration
Ratio Secondary
2654
Int32
4
R W
n/a
1=1 5=5
Gen Current
Configuration
Rated Primary
2656
Float
4
R
Amp
0–180000
Gen Bus
Configuration
Rated kVA
2658
Float
4
R W
KVA
1–1000000
Gen Bus
Configuration
Rated PF
2660
Float
4
R W
PF
-2 – 2
Gen Bus
Configuration
Rated kW
2662
Float
4
R
kW
-2000000
Gen Bus
Configuration
Rated kvar
2664
Float
4
R
Kvar
0–1000000
Gen Bus
Configuration
Rotation
2666
Int32
4
R W
n/a
ABC=0 ACB=1
Field Voltage
Configuration
Rated Field Voltage Full Load
2668
Float
4
R W
Volt
1–125
Field Voltage
Configuration
Rated Field Voltage No Load
2670
Float
4
R W
Volt
1–125
Field Current
Configuration
Rated Field Current No Load
2672
Float
4
R W
Amp
0.1–7
Field Current
Configuration
Rated Field Current Full Load
2674
Float
4
R W
Amp
0.1–7
Boot
Configuration
Pwm Duty
2676
Uint32
4
R W
Percent
0–100
DECS Control
Start Stop Request
2678
Uint32
4
R W
n/a
Stop=0 =1 Start =2
DECS Control
System Option Underfrequency Hz
2680
Float
4
R W
Hertz
10–75
DECS Control
System Input COM Port Manual Enabled
2682
Uint32
4
R W
n/a
Manual=1 Automatic=2
DECS Control
System Input COM Port PF var Enabled
2684
Uint32
4
R W
n/a
Off=0 PF=1 Var=2
DECS Control
System Input COM Port Internal Tracking
Enabled
2686
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Input COM Port External Tracking
Enabled
2688
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Input COM Port Pre-position
Enabled
2690
Uint32
4
R W
n/a
NOT SET=0 SET=1
DECS Control
System Input COM Port Pre-position
Enabled 2
2692
Uint32
4
R W
n/a
NOT SET=0 SET=1
DECS Control
System Input COM Port Raise Enabled
2694
Uint32
4
R W
n/a
NOT SET=0 Raise=1
DECS Control
System Input COM Port Lower Enabled
2696
Uint32
4
R W
n/a
NOT SET=0 Lower=1
DECS Control
System Option Input Droop Enabled
2698
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Input Line Drop Enabled
2700
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Input Cross Current
Enabled
2702
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Input OEL Style Enabled
2704
Uint32
4
R W
n/a
Summing=0 Takeover=1
DECS Control
System Option Input Voltage Match
Enabled
2706
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Input OEL Enabled
2708
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Input UEL Enabled
2710
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Input SCL Enabled
2712
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Loss of Sensing Transfer
to Manual Mode
2714
Uint32
4
R W
n/a
Status Only=0 Transfer to
Manual=1 Shutdown=2
DECS Control
System Option Underfrequency Mode
2716
Uint32
4
R W
n/a
UF Limiter=0
V/Hz Limiter=1
DECS Control
System Option PSS Power Level Enabled
2718
Uint32
4
R W
Disabled=0 Enabled=1
DECS Control
System Option Volts per Hertz Slope High
2720
Float
4
R W
n/a
0–3
DECS Control
System Option Volts per Hertz Slope Low
2722
Float
4
R W
n/a
0–3
DECS Control
System Option Volts per Hertz Slope Time
2724
Float
4
R W
Second
0–10
DECS Control
System Option Voltage Match Band
2726
Float
4
R W
Percent
0–20
DECS Control
System Option Voltage Match Reference
2728
Float
4
R W
Percent
0–700
