25-28 9492600990
Modbus
®
Communication DECS-150
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Field Overvoltage
Secondary Time
Delay
3142
Float
4
R W
Millisecond
Instantaneous=0, 030000
Loss Of Sensing
Mode
3144
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Loss Of Sensing
Time Delay
3146
Float
4
R W
Second
0–30
Loss Of Sensing
Voltage Balanced
Level
3148
Float
4
R W
Percent
0–100
Loss Of Sensing
Voltage Unbalanced
Level
3150
Float
4
R W
Percent
0–100
EDM
Mode
3152
Uint32
4
R W
n/a
Disabled=0 Enabled=1
EDM
Pickup
3154
Float
4
R W
Amp
0; 110
EDM
Time Delay
3156
Float
4
R W
Millisecond
0; 20030000
25
Mode
3158
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
Slip Angle
3160
Float
4
R W
Degree
1–99
25
Slip Frequency
3162
Float
4
R W
Hertz
0.010.5
25
Voltage Difference
3164
Float
4
R W
Percent
0.150
25
Generator
Frequency Greater
Than Bus
Frequency
3166
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
Angle
Compensation
3168
Float
4
R W
Degree
0–359.9
27P
Primary Mode
3170
Uint32
4
R W
n/a
Disabled=0 Enabled=1
27P
Primary Pickup
3172
Float
4
R W
Volt
Disabled=0, 099999
27P
Primary Time Delay
3174
Float
4
R W
Millisecond
10060000
27P
Secondary Mode
3176
Uint32
4
R W
n/a
Disabled=0 Enabled=1
27P
Secondary Pickup
3178
Float
4
R W
Volt
Disabled=0, 0999999
27P
Secondary Time
Delay
3180
Float
4
R W
Millisecond
10060000
59P
Primary Mode
3182
Uint32
4
R W
n/a
Disabled=0 Enabled=1
59P
Primary Pickup
3184
Float
4
R W
Volt
Disabled=0, 099999
59P
Primary Time Delay
3186
Float
4
R W
Millisecond
10060000
59P
Secondary Mode
3188
Uint32
4
R W
n/a
Disabled=0 Enabled=1
59P
Secondary Pickup
3190
Float
4
R W
Volt
Disabled=0, 099999
59P
Secondary Time
Delay
3192
Float
4
R W
Millisecond
10060000
81O
Primary Mode
3194
Uint32
4
R W
n/a
Disabled=0 Over=1
81O
Primary Pickup
3196
Float
4
R W
Hertz
Disabled=0, 30 - 70
81O
Primary Time Delay
3198
Float
4
R W
Millisecond
100 - 300000
81O
Primary Voltage
Inhibit
3200
Float
4
R W
Percent
0; 5 - 100
81O
Secondary Mode
3202
Uint32
4
R W
n/a
Disabled=0 Over=1
81O
Secondary Pickup
3204
Float
4
R W
Hertz
Disabled=0, 3070
81O
Secondary Time
Delay
3206
Float
4
R W
Millisecond
100300000
81O
Secondary Voltage
Inhibit
3208
Float
4
R W
Percent
0; 5100
81U
Primary Mode
3210
Uint32
4
R W
n/a
Disabled=0 Under=2
81U
Primary Pickup
3212
Float
4
R W
Hertz
Disabled=0, 3070
81U
Primary Time Delay
3214
Float
4
R W
Millisecond
100300000
81U
Primary Voltage
Inhibit
3216
Float
4
R W
Percent
Disabled=0, 5100
81U
Secondary Mode
3218
Uint32
4
R W
n/a
Disabled=0 Under=2
81U
Secondary Pickup
3220
Float
4
R W
Hertz
Disabled=0, 3070
81U
Secondary Time
Delay
3222
Float
4
R W
Millisecond
100300000
81U
Secondary Voltage
Inhibit
3224
Float
4
R W
Percent
Disabled=0, 5100
