Check Engine Coolant Level
1. Skidsteer must be parked on a level surface,
lift arms fully lowered, engine stopped and key
removed.
2. Loosen knobs (A) and tilt hydraulic cooler up.
Engage pin to hold cooler in open position.
A
A
Note: Expansion tank is mounted above the
engine radiator.
3. Check coolant level in expansion tank. Coolant
should be between indicator marks (B).
4. If coolant level is low, remove expansion tank
cap (C).
5. If expansion tank is empty, check coolant level
in radiator.
6. Lift tank approximately 1 in. (25 mm) and
remove from skidsteer.
B
7. Add a premixed coolant or a 50/50 mix of water
and anti-freeze to proper level.
8. Install tank and cap.
9. Close hydraulic cooler.
