4.8 Lift Arm Lock
^ WARNING
Crushing hazard.
Raised unsupported lift arms can fall,
resulting in death or serious injury.
Never enter the area under raised lift
arms.
Engage Lift Arm Lock
1. Start engine.
2. Verify the area is clear of bystanders and
obstructions, and fully raise lift arms.
3. Engage park brake, shut off engine and
remove key.
4. Remove quick lock pin (A) and pivot lift arm
lock down until resting on cylinder ram (B).
A
B
Lift Arm Lock Disengaged
^ WARNING
Prevent serious injury or death.
Do not operate or drive the skidsteer on
roadways.
^ WARNING
Tip over hazard.
When loading onto a trailer, back onto
trailer for better weight balance to avoid
tip over.
1. Raise attachment slightly off ground.
2. Travel at a reasonable and safe speed.
When transporting the skidsteer on a trailer, use
the following procedure:
1. Lower lift as low as possible.
2. Back skidsteer onto trailer.
3. Lower lift arms to trailer deck.
4. Engage park brake and stop engine.
5. Secure skidsteer to trailer with the proper size
and load rated tie downs.
4.7 Transporting
33
