Baumalight TRL620D - Every 500 Hours; Replace Fuel Filter; Replace Hydraulic Filter

5.6 Every 500 Hours
Replace Fuel Filter
1. Skidsteer must be parked on a level surface,
park brake engaged, lift arms fully lowered,
engine stopped and key removed.
2. Loosen knobs and remove cover (A).
3. Fuel lter (B) is located behind panel. Replace
lter every 500 hours.
B
A
Replace Hydraulic Filter
Replace hydraulic lter every 500 hours.
1. Skidsteer must be parked on a level
surface, park brake engaged, lift arms fully
lowered, engine stopped and key removed.
Allow hydraulic system to cool to ambient
temperature.
2. Loosen knobs and remove cover (A).
A
3. Close valve between tank and hydraulic lter
head.
4. Remove and replace hydraulic lter (B).
B
5. Install cover (A), open valve and check hydraulic
uid level. Add hydraulic uid if necessary.
AW32 is recommended for general conditions
and climates. MV22 is recommended for colder
climates.
46
