5 SERVICE AND
MAINTENANCE
5.1 Safety
^ WARNING
Prevent death or serious injury.
1. Park machine on rm, level surface.
2. Engage park brake.
3. Verify all controls are in neutral.
4. Stop engine and remove key.
^ WARNING
Prevent death or serious injury.
Raised unsupported lift arms can fall,
resulting in death or serious injury.
Never enter the area under raised lift
arms.
5.2 Daily Or Every 10 Hours
Check Engine Oil Level
1. Skidsteer must be parked on a level surface,
park brake engaged, lift arms fully lowered,
engine stopped and key removed.
2. Loosen knobs (A) and pivot hydraulic oil cooler
upward. Engage pin to hold cooler in open
position.
A
A
3. Check oil level on dipstick (B). Oil level should
be at full mark on dipstick. Add OEM specied
engine oil as necessary through ll port (C) on
valve cover.
B
C
38
