Baumuller BUS 6 VC - 7.2 Power Unit

Parameter
V-Controller (BUS 6 VC) 33
Baumüller Nürnberg Electronic GmbH & Co. KG 5.03047.01
7.2 Power Unit
Parameter overview
Parameter description
P115 PU state
This parameter displays the state of the power unit.
Parameter Name Range
min. ... max.
Unit Display
only
P115 PU state 0000 ... FFFF
!
P090 PU mode 0000 ... 0007
P117 PU type 0.1 ... 65535
!
P114 PU I nominal 0.1 ... 2500,0 A
!
P113 PU I max 0.1 ... 2500,0 A
!
P119 PU overload time 0.00 ... 600,00 s
!
P116 PU I limit The range depends on the PU.
Permitted range:
≤ PU I limit ≤ PU I max
A
P118 PU temperature -80 ... 130 °C
!
Bit no. Meaning
0 ... 2 0 : STOP 1 : RUN
3 1 : Error in function module, error code see M error code (P124)
4 1 : Power unit reset is active
5 1 : Pulses are enabled, power unit is active
6 1 : Power unit temperature > 80 °C
7 1 : Power unit ready for use
8 1 : PU monitoring is active, current reduction to 100% I
nom
power unit
9 1: Short circuit temperature sensor
10 ... 15 reserved
PU Inom
