Baumuller BUS 6 VC - 7.6 Uzk Controller (Uzk value setting)

Parameter
V-Controller (BUS 6 VC) 45
Baumüller Nürnberg Electronic GmbH & Co. KG 5.03047.01
7.6 Uzk Controller (Uzk value setting)
Parameter overview
Parameter description
P059 N state
This parameter shows the Uzk controller´s state.
P057 N P gain
P gain (K
p
) of Uzk controller.
Parameter Name Range
min. ... max.
Unit Display
only
P059 N state 0000 ... FFFF
!
P057 N P gain 0,1 ... 1000,0
P058 N integral action time 0,0 ... 2000,0 ms
P087 ES U
ZK
nominal value 280 ... 1000 V
P050 N Uzk set value 150,0 ... 999,9 V
P047 N Uzk additional set value -10,00 ... 10,00 V
P204 N Uzk set value max. 550,0 ... 999,9 V
P205 N Uzk set value min. 150,0 ... 950,0 V
P051 N Uzk actual value -1999,9 ... 1999,9 V
!
P052 N Uzk controller output -100,00 ... 100,00 %
P054 N I max. feed back current/IR1 0,00 ... 100,00 %
P055 N I max. feed-in current/IR2 0,00 ... 100,00 %
P060 N Uzk control deviation -199,99 ... 199,99 %
!
P061 N Uzk limit control deviation 0,00 ... 199,99 %
Bit no. Meaning
0 ... 2
000: STOP, N Uzk controller is disabled
001: RUN, N Uzk controller is enabled
011: STAND_BY, N-Uzk controller is disabled
3
1: error in module, error code see P124
4
reserved
5 ... 9
reserved
10
reserved
11
0: current direction 1 active
1: current direction 2 active
12
1: set value reached (|deviation P060| < limiter deviation (P061)
13
1: limiter set value reached (current limiter)
14 ... 15
reserved
