Parameter
44 V-Controller (BUS 6 VC)
5.03047.01 Baumüller Nürnberg Electronic GmbH & Co. KG
P077 I I
d
set value
P078 I I
d
actual value
The direct-axis current set value / actual value (reactive current component if the vector con-
trol) is displayed here.
P076 I U
d
set value
Manipulated variable of direct-axis controller
.
P070 I phase voltage L1
P086 I phase voltage L2
Voltage set values on unit‘s connection 1U1 and 1V1
P073 I phase current L1
P074 I phase current L2
P083 I current offset U
P084 I current offset V
To compensate the offset of the current transformer, the current transformer is set to 0 at ev-
ery pulse enabling. This parameter shows the offset value.
P099 I apparent current actual value
Standardization: 100 % ↔ PU I limit (P116)
Standardization: 100 % ↔ (effective value)
Standardization: 100 % ↔ (effective value)
Standardization: 100 % ↔ PU I limit (P116)
Standardization:
100% ↔
2
11
(half of the measuring transducer range)
Standardization: 100 % ↔ PU I limit (P116)
U
ZKnom
P087()
08, 32⋅⋅
--------------------------------------
U
ZKnom
P087()
08, 32⋅⋅
--------------------------------------
