9.3 Parameter List
Parameter Default Internal scaling Page
- P001 RFG output - ±100,00 % = ±16383 dec 70
- P014 RFG state - 1:1 68
- P034 MM clockwise rotating field 0 1:1 43
- P047 N Uzk additional set value - -10,00 ... 10,00 46
- P050 N Uzk set value - ±100,00 % = ±16384 dez 46
- P051 N Uzk actual value - ±100,00 % = ±16384 dez 46
- P052 N Uzk controller output - ±100,00 % = ±16384 dez 46
- P054 I max. feed back current - 0,00 ... 100,00 46
- P055 I max. output current - 0,00 ... 100,00 46
- P059 N state - 1:1 45
- P060 N Uzk control deviation - ±100,00 % = ±16384 dez 46
- P068 I Iq controller output - ±100,00 % = ±16384 dec 43
- P068 I U_mains pre-control - ±100,00 % = ±16384 dec 43
- P070 I phase voltage L1 - ±100,00 % = ±16384 dez 44
- P071 I Id set value - ±100,00 % = ±16384 dec 43
- P072 I Id actual value - ±100,00 % = ±16384 dec 43
- P073 I phase current L1 - ±100,00 % = ±10922 dez 44
- P074 I phase current L2 - ±100,00 % = ±10922 dez 44
- P075 I Uq set value - ±100,00 % = ±16384 dez 43
- P076 I Ud set value - ±100,00 % = ±16384 dec 44
- P077 I Id set value - ±100,00 % = ±16384 dec 44
- P078 I Id actual value - ±100,00 % = ±16384 dec 44
- P083 I current offset U - ±25,00 % = ±8188 dec 44
- P084 I current offset V - ±25,00 % = ±8188 dec 44
- P086 I phase voltage L2 - ±100,00 % = ±16384 dez 44
- P087 ES Uzk nominal value - 550 ... 1000 46
- P099 I apparent current actual value - ±100,00 % = ±16384 dec 44
- P100 PWM phase L1 - ±100,00 % = ±16384 dez 40
- P101 PWM phase L2 - ±100,00 % = ±16384 dez 40
- P102 PWM phase L3 - ±100,00 % = ±16384 dez 40
- P113 PU I max - 100,0 A = 1000 dez 35
- P114 PU I nominal - 100,0 A = 1000 dec 35
- P115 PU state - 1:1 33
- P117 PU type - 1:1 34
- P118 PU temperature - 80° C = 80 dec 36
- P120 M control word - 1:1 50
- P121 M state word - 1:1 51
- P123 M actual operation mode - 1:1 52
- P124 M error code - 1:1 52
- P125 M error index - 1:1 52
- P137 M state 1 - 1:1 52
- P138 Language 1 1:1 65
- P139 PU Ixt value - ±100,00 % = ±16384 dec 37
X: Parameter is saved in the data record
