Parameter
V-Controller (BUS 6 VC) 43
Baumüller Nürnberg Electronic GmbH & Co. KG 5.03047.01
P034 MM clockwise rotating field
This parameter adapts the control to the motor´s rotating field.
P071 I Iq set value
P072 I Iq actual value
The cross current specified/actual value (active current component of the vector control) is
indicated here. 100 % corresponds to the value set in the LT I limit (P116).
P068 I I
q
controller output
Manipulated variable of active current controller.
P069 I U mains pre-control
Pre-control of mains voltage (corresponds with the EMF of the motor).
P075 I U
q
set value
Sum of P068 I
q
controller output and P069 U mains pre-control.
Value Meaning
0 mains with counterclockwise rotating field (phase L2 and L3 changed)
1 mains with clockwise rotating field
NOTE
After changing the MM rotating field the data set 0 must be saved (boot data set) and the
controller must be re-booted!
Standardization: 100 % ↔
Standardization: 100 % ↔ (effective value)
Standardization: 100 % ↔ (effective value)
U
ZKnom
P087()
32⋅
--------------------------------------
U
ZKnom
P087()
08, 32⋅⋅
--------------------------------------
U
ZKnom
P087()
08, 32⋅⋅
--------------------------------------
