Baumuller BUS 6 VC - 7.13 Analog Inputs

Parameter
74 V-Controller (BUS 6 VC)
5.03047.01 Baumüller Nürnberg Electronic GmbH & Co. KG
Parameter overview
Parameter description
P302 AI state
This parameter indicates the status of the analog inputs module.
P277 AI 1 input channel
P284 AI 2 input channel
Entry of the analog input for respective channel.
The two hardware implemented analog inputs 1 and 2 can be connected with each input
channels. It is further possible to connect an analog input with different input channels.
P278 AI 1 smoothing
P285 AI 2 smoothing
In order to smooth interference on the analog input signal a smoothing time constant can be
entered in ms. Smoothing is switched off if the respective parameter is set to its minimum
value.
Parameter Name Range
min. ... max.
Unit Display
only
P302 AI state 0000 ... FFFF
!
P277 AI 1 input channel 0 ... 1
P278 AI 1 smoothing 1 ... 30 ms
P279 AI 1 scaling -2,00 ... 2,00
P280 AI 1 target Pxxx 0 ... 700
P281 AI 1 offset -100,00 ... +100,00 %
P282 AI 1 threshold value 0,00 ... 100,00 %
P283 AI 1 value -100,00 ... +100,00 %
!
P284 AI 2 input channel 0 ... 1
P285 AI 2 smoothing 1 ... 30 ms
P286 AI 2 scaling -2,00 ... 2,00
P287 AI 2 target Pxxx 0 ... 700
P288 AI 2 offset -100,00 ... +100,00 %
P289 AI 2 threshold value 0,00 ... 100,00 %
P290 AI 2 value -100,00 ... +100,00 %
!
Bit No. Meaning
0 0: Evaluation of analog input 1 disabled
1: Evaluation of analog input 1 enabled
1 0: Evaluation of analog input 2 disabled
1: Evaluation of analog input 2 enabled
2 ... 15 reserved
