Baxi POWER HT+ Series Installation And Service Manual

P
Parameter
number
Parameter Description Factory set
ting
5931 S
Sensor input BX2 None
: No function on the sensor input.
Hot water sensor B31
: Sensor in the bottom section of the DHW
tank.
Collector sensor B6
: Solar collector sensor.
HW circulation sensor B39
: Circulation / DHW preparation sensor.
Buffer sensor B4
: Sensor in the top section of the storage tank.
Buffer sensor B41
: Sensor in the bottom section of the storage tank.
Flue gas temp sensor B8
: Flue gas sensor
Common flow sensor B10
: Common flow sensor (cascade).
Solid fuel boiler sensor B22
: Sensor for solid fuel boiler.
HW charging sensor B36
Buffer sensor B42
: Third sensor (in the middle) of the storage tank.
Common return sensor B73
Cascade return sensor B70
: Cascade return sensor.
Swimming pool sensor B13
: Swimming pool sensor.
Solar flow sensor B63
: Solar flow sensor for measuring efficiency.
Solar return sensor B64
: Solar return sensor for measuring efficien
cy.
Primary exch sensor B26
None
5932 S
Sensor input BX3
See
Sensor input BX2
None
5970 F
Function input H4 None
: Default setting for boilers with DHW tank.
Flow measurement Hz
: Default setting for instantaneous boilers.
Error/alarm message
None
5971 C
Contact type H4 NC
NO
Error/alarm
message
5973 F
Frequency value 1
H4
Definition of parameters for collector specifications 15
5974 F
Function value 1 H4
Definition of parameters for collector specifications 20
5975 F
Frequency value 2
H4
Definition of parameters for collector specifications 162
5976 F
Function value 2 H4
Definition of parameters for collector specifications 120
9 Settings
80 7609474 - v02 - 04092014
