Baxi POWER HT+ Series Installation And Service Manual

S
See
Fan speed according to gas type, page 59.
Fan speed according to gas type
Tab.20 Fan speed for gas type G20
Parameter Output Unit POWER HT+
1.50
POWER HT+
1.70
POWER HT
+ 1.90
POWER HT+
1.110
9524 R
Required speed LF
minimum rpm 1500 1270 1250 1300
9524 R
Required speed LF
minimum for
boilers in
cascade
rpm 1700 1470 1450 1500
9529 R
Required speed HF
2441 F
Fan speed heating max
maximum rpm 6650 6450 6500 6900
9512 R
Required speed ignition
Ignition rpm 2300 2100 2400 2500
Tab.21 Fan speed for gas type G25
Parameter Output Unit POWER HT+
1.50
POWER HT+
1.70
POWER HT
+ 1.90
POWER HT+
1.110
9524 R
Required speed LF
minimum rpm 1500 1270 1250 1300
9524 R
Required speed LF
minimum for
boilers in
cascade
rpm 1700 1470 1450 1500
9529 R
Required speed HF
2441 F
Fan speed heating max
maximum rpm 6650 6450 6500 6900
9512 R
Required speed ignition
Ignition rpm 2300 2100 2400 2500
Tab.22 Fan speed for gas type G31
Parameter Output Unit POWER HT+
1.50
POWER HT+
1.70
POWER HT
+ 1.90
POWER HT+
1.110
9524
Required speed LF
minimum rpm 1500 1270 1500 1300
9524 R
Required speed LF
minimum for
boilers in
cascade
rpm 1700 1470 1650 1500
9529 R
Required speed HF
2441 F
Fan speed heating max
maximum rpm 6400 6100 6200 6700
9512 R
Required speed ignition
Ignition rpm 3000 2500 2400 3000
7.4.2 Setting the air/gas ratio (maximum thermal flow rate)
Unscrew the plug in the measurement point.
7 Commissioning
7609474 - v02 - 04092014 59
