Baxi POWER HT+ Series Installation And Service Manual

2 About this manual
2
2.1 General
This manual is intended for the installer of a POWER HT + boiler.
2.2 Symbols used
2.2.1 Symbols used in the manual
This manual uses various danger levels to draw attention to special in
structions. We do this to improve user safety, to prevent problems and to
guarantee correct operation of the appliance.
Danger
Risk of dangerous situations resulting in serious personal injury.
Danger of electric shock
Risk of electric shock.
Warning
Risk of dangerous situations resulting in minor personal injury.
Caution
Risk of material damage.
Note
Please note: important information.
See
Reference to other manuals or pages in this manual.
2.2.2 Symbols used on the appliance
1
Alternating current.
2
Protective earthing.
3
Before installing and commissioning the appliance, carefully read
the instruction manuals provided.
4
Dispose of used products through an appropriate recovery and re
cycling structure.
5
Caution: danger of electric shock, live parts. Disconnect the mains
power prior to carrying out any work.
2.3 Abréviations
Hi
Lower heating value (LHV)
Hs
Higher heating value (HHV)
PCU
PCB for managing burner operation
SU
Safety PCB
Fig.1 Symbols used on the appliance
1 2
MW-2000068-1
1
2
3
4
5
2 About this manual
10 7609474 - v02 - 04092014

Baxi POWER HT+ Series Specifications

General

Model	POWER HT+ Series
Category	Boiler
Installation Type	Wall-mounted
Heat Exchanger Material	Stainless Steel
Warranty	2 years
Fuel Type	Natural Gas
Control System	Integrated Control
Ignition Type	Electronic
