Baxi POWER HT+ Series User Manual

6. Disconnect the ignition electrode and the flame detection sensor.
7. Disconnect the 2 wires from the safety thermostat on the combustion
chamber door and the pin under the ignition electrode.
8. Remove the gas valve connector.
Fig.147
MW-2000805-01
6
6
Fig.148
MW-2000806-01
7
7
Fig.149
MW-2000807-01
8
11 Maintenance
7702630 - v02 - 11082018 POWER HT + 109

Baxi POWER HT+ Series Specifications

General

Model	POWER HT+ Series
Category	Boiler
Installation Type	Wall-mounted
Heat Exchanger Material	Stainless Steel
Warranty	2 years
Fuel Type	Natural Gas
Control System	Integrated Control
Ignition Type	Electronic
