Bay-Tek AXE MASTER User Manual

52
GAME LIGHTING WIRING DIAGRAM
For games manufactured before July 2022
Front Console
Rear Section
Middle Section
Middle Section
AACB29000
Control Board
AACE29010
From Power
Dist Board
AACE29036
AACE29046
Left Console LED’s
AACE29046
Right Console LED’s
AACE29020
AACE29020
AACE29048
Side Cage
Stick Light
+ -
AACE29019
AACE29032
AACE29045
Lights behind Target Area
AACE29041
AACE29041
AACE29048
Side Cage
Stick Light
+ -
AACE29017
AACE29017
AACB8001-HH
Light Board
AACE29011
Power In
from Power
Dist. Board
A5CBL5900
USB communication
to motherboard
Red and Yellow
Communication LEDs ON
Green Power LED Flashing
AACE29060
Left Side Arrow LED’s
Right Side Arrow LED’s
AACE29060
AACE29044
AACE29044
AACE29044
AACE29044
AACE29059
AACE29016 To
Safety Wall LED’s
