Bay-Tek quik drop User Manual


JACKPOT DISPLAY, SPEAKER, CAROUSEL MOTOR & BALL DROP SOLENOID
To J22
Connector
Ground
Wire
AACE5855
AACE5823
"#"
$%&'
()*+,-".
*#%
3.5 Amp Fuse
(A5FUFB010)
AASO5800
Ball Drop
Solenoid
4.1 Ohms
AACE5810
12 Volts Power In
from Power Supply
These
connectors
are colored
Orange
AACE5825
/
Speaker
AACE8811
AACE5828
To J19
Speakers
Connector
AACE5842

 

AACE3892
A5LD1058
Jackpot Display
AACE5843
AANEWGEN1-PJ/RBN

'0
!
AACE5844
Top Window
LED’s
AACE5846
Around Drop
Button LED’s
!
AACE5847
Behind Ball
Drop LED’s
AACE5845
Control
Panel LED’s
AACE5844
Bottom
Window
LED’s
5 Amp Fuse
(A5FUSE11)
AACE5859
AACE5823
5 Volts from
Power Supply
5 Volts from
Power Supply

 

