TX1500 Manual V3.5 Dec 07 Page 36 of 40 TX1500/BBUS-I/F INTERFACE
Relay ON (Triangle Key) @50,X<CR>
X = 0 – 12
0 = Tx1500 relay
1 – 2 = relays 1 & 2 of alarm card 1
3 – 4 = relays 1 & 2 of alarm card 2
5 – 6 = relays 1 & 2 of alarm card 3
7 – 8 = relays 1 & 2 of alarm card 4
9 – 10 = relays 1 & 2 of alarm card 5
11 – 12 = relays 1 & 2 of alarm card 6
Relay OFF @51,X<CR> X = As above
HASH command @52,X<CR>
X = hash number – see Tx1500 for specific
hash commands.
Send Single Key Press @53,0<CR> ‘0’ Key
@53,1<CR> ‘1’ Key
@53,2<CR> ‘2’ Key
@53,3<CR> ‘3’ Key
@53,4<CR> ‘4’ Key
@53,5<CR> ‘5’ Key
@53,6<CR> ‘6’ Key
@53,7<CR> ‘7’ Key
@53,8<CR> ‘8’ Key
@53,9<CR> ‘9’ Key
@53,10<CR> ‘CAMERA’ key
@53,11<CR> ‘MONITOR’ key
@53,12<CR> ‘CLEAR’ key
@53,13<CR> ‘+’ key
@53,14<CR> ‘-‘ key
@53,15<CR> ‘PRESET’ key
@53,16<CR> ‘PATROL’ key
@53,17<CR> ‘SEQ’ key
@53,18<CR> ‘RELAY/TRIANGLE’ key
@53,19<CR> ‘ALARM’ key
@53,21<CR> ‘PROGRAM’ key
@53,22<CR> TX1500 MENU ACCESS
Display current Info @54<CR>
Output current camera, monitor & lights
status
All characters shown are the actual ASCII characters that should be sent. Two or three digit numbers will be sent
using either two or three characters.
All commands are terminated with a <CR> = 0x0d or decimal 13
