BBV TX1500 system - TX1500 System Example

TX1500 Manual V3.5 Dec 07 Page 5 of 40 TX1500 MATRIX EXAMPLE
Rx100
+ dome camera
STATIC
Rx200
+ panning camera
Rx300
+ pan/tilt camera
Rx400P
+ preset pan/tilt camera
TX1500/16/8/16AL Matrix
TX1500/KBD
Rx400DC
+ DC preset pan/tilt
camera
video in - coax
RS485 StarCard 8 outputs
TX1500/KBD TX1500/KBD
RJ45 Breakout
Box
twin STP
Rx45X
Multi-protocol
+ AC Preset pan/tilt
camera
Rx55X
Multi-protocol
+ DC preset pan/tilt
camera
