BBV TX1500 system - TX1500 CONTROL PROTOCOL; PROTOCOL COMMANDS AND FUNCTIONS

TX1500 Manual V3.5 Dec 07 Page 35 of 40 TX1500/BBUS-I/F INTERFACE
TX1500 control protocol via the TX1500/BBUS/I-F
The ZP-TX1500 matrix can be controlled using a simple serial protocol with the use of a TX1500/BBUS/I-F
interface. The protocol is described on the following pages.
Baud settings: 9600,N,8,1. Timing is not critical.
Function String Notes
SELECT MONITOR @2,M <CR> M = monitor number (1 - 8)
SELECT CAMERA @3,C <CR> C = camera number (1 - 96)
PAN RIGHT @5,2 <CR>
PAN LEFT @5,3 <CR>
TILT UP @5,4 <CR>
TILT DOWN @5,5 <CR>
ZOOM IN @5,6 <CR>
ZOOM OUT @5,7 <CR>
FOCUS FAR @5,8 <CR>
FOCUS NEAR @5,9 <CR>
IRIS CLOSE @5,10 <CR>
IRIS OPEN @5,11 <CR>
WASH ON @5,12 <CR>
WIPER ON @5,19 <CR>
LAMPS ON @5,21 <CR>
STOP PAN RIGHT @6,2 <CR>
STOP PAN LEFT @6,3 <CR>
STOP TILT UP @6,4 <CR>
STOP TILT DOWN @6,5 <CR>
STOP ZOOM IN @6,6 <CR>
STOP ZOOM OUT @6,7 <CR>
STOP FOCUS FAR @6,8 <CR>
STOP FOCUS NEAR @6,9 <CR>
STOP IRIS CLOSE @6,10 <CR>
STOP IRIS OPEN @6,11 <CR>
STOP WASH ON @6,12 <CR>
STOP WIPER ON @6,19 <CR>
STOP LAMPS ON @6,21 <CR>
STOP PAN/TILT/LENS @6,22 Stops all pan/tilt and lens movement
PAN/TILT SPEED @7,P,T <CR>
P=Pan & T=Tilt speed in the range 0 - 15
0 = slowest, 15 = fastest
GOTO PRESET @8,P <CR> P = preset number (1-99)
PROGRAM PRESET @9,P <CR> P = preset number (1-99)
START PATROL 1 @10 <CR>
START AUTOPAN @12 <CR>
START MONITOR
SEQUENCE
@25,0 <CR> Same as hold off
STOP MONITOR
SEQUENCE
@25,1 <CR> Same as hold on
