Mainboard Specifications
Model RX35Q
Processor Intel® Core 2 Processor
Socket 775 supports Core 2 Quad, Core 2 Duo, Pentium D CPU
Supports CPU FSB 800/1066/1333 MHz
North Bridge Intel® Q35
Memory
DDR2 800/667 SDRAM
* Supports DDR2 667 (PC2-5300), DDR2 800 (PC2-6400) memory modules up to
8GB max. (2GB max/ DIMM slot)
* DDR2 667MHz recommended for 8GB configuration
* 4 DDR2 DIMM slots (240-pin/ 1.8V), supports Non-ECC, un-buffered memory
Integrated Graphics Intel® GMA 3100 Engine; up to 256MB can be allocated for GFX
South Bridge Intel® ICH9
4 x SATA II connectors supports 3.0 Gbs transfer speed SATA
1 x SATA II connector from Marvell 88SE6111
PCI-E 1 x PCI-E x 16 slot and 1 x PCI-E x 1 slot
PCI 2 x PCI Slots (PCI 2.2 compliant)
USB 10 x USB 2.0 ports (4 x Rear I/O, 6 x header)
Marvell® 88SE6111 IDE
1 x Ultra DMA 66/100/133 IDE controller
Infineon® TPM TPM
1 x TPM 1.2 Security Device
Super I/O Controller Fintek® F71882FG
Floppy Controller 1 x std. floppy controller
Serial Ports 2 x RS232 port (1 x Rear I/O, 1 x header)
Watch Dog Timer 1 ~ 255 sec timer
HW Monitor Yes
Realtek® ALC888 Audio
HD Audio Codec with auto jack sensing
Intel® 82566 LAN
1 x 10/100/1000 LAN
VIA® 6308 1394
1 x VIA PCI 1394 controller
AMI® BIOS BIOS
AMI Bios with 16Mb SPI ROM
